SKU: UELFL206-103D1-NTN
NTN UELFL206-103D1 Imperial Two Bolt Cast Iron Oval Housing with 1-3/16 inch Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL206-103D1 Imperial Two Bolt Cast Iron Oval Housing with 1-3/16 inch Bore Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 30.16mm = 1.187 (1-3/16) inch
- Style:
- UELFL
- Bolt Hole Centres:
- 4-39/64 inch
Technical
Technical
| Shaft diameter | 1-3/16 inch |
|---|---|
| H | 5-13/16 inch |
| J | 4-39/64 inch |
| A<sub>2</sub> | 45/64 inch |
| A<sub>1</sub> | 1/2 inch |
| A | 1-7/32 inch |
| N | 5/8 inch |
| L | 3-5/32 inch |
| A<sub>0</sub> | 1-57/64 inch |
| B<sub>1</sub> | 1.906 inch |
| S | 0.719 inch |
| F min. | 1-25/32 inch |
| Fixing bolt | 1/2 inch |
| Mass | 2.2 lbs |
