SKU: UELFL204-012D1W3-NTN
NTN UELFL204-012D1W3 Imperial Two Bolt Cast Iron Oval Housing with 3/4 inch Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL204-012D1W3 Imperial Two Bolt Cast Iron Oval Housing with 3/4 inch Bore Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- UELFL
- Bolt Hole Centres:
- 3-35/64 inch
Technical
Technical
| Shaft diameter | 3/4 inch |
|---|---|
| H | 4-7/16 inch |
| J | 3-35/64 inch |
| A<sub>2</sub> | 19/32 inch |
| A<sub>1</sub> | 7/16 inch |
| A | 1 inch |
| N | 15/32 inch |
| L | 2-3/8 inch |
| A<sub>0</sub> | 1-41/64 inch |
| B<sub>1</sub> | 1.72 inch |
| S | 0.673 inch |
| F min. | 1-11/32 inch |
| Fixing bolt | 3/8 inch |
| Mass | 1.1 lbs |
