SKU: UCFC.218-56
UCFC218-56 Imperial Four Bolt Cast Iron Round Flanged Housing with 3-1/2 inch Insert
UCFC218-56 Imperial Four Bolt Cast Iron Round Flanged Housing with 3-1/2 inch Insert
Out of stock
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 88.9mm = 3.5 (3-1/2) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 219.87mm = 219.87 (8-21/32) inch
Technical
Technical
| d | 3-1/2 inch |
|---|---|
| a | 10-7/16 inch |
| P | 8-21/32 inch |
| e | 6-1/8 inch |
| i | 55/64 inch |
| L | 2-11/16 inch |
| s | 29/32 inch |
| j | 45/64 inch |
| k | 25/32 inch |
| g | 1-31/32 inch |
| f | 7.4803 inch |
| z | 3-3/32 inch |
| Bi | 3.7795 inch |
| n | 1.5630 inch |
| Bolt Size | 3/4 inch |
| Weight | 13 kg |
| Dynamic load | 7500 kgf |
| Static load | 6170 kgf |
