SKU: TSF18R-ISB
ISB TSF18R Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M18 Thread
ISB TSF18R Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M18 Thread
Equivalent to: TSF18R
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M18x1.5
- Thread M / F:
- Female
- Thread Direction:
- Right Hand
- Bore:
- 18
- Inside Diameter:
- 18
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 18mm |
|---|---|
| d1 | 21.8mm |
| d2 | 44mm |
| d3 | M 18x1.5mm |
| d4 | 25mm |
| d5 | 31mm |
| B | 23mm |
| C1 | 15mm |
| h1 | 71mm |
| I3 | 36mm |
| I5 | 10mm |
| P | 8.5mm |
| W | 27mm |
| Ø | 31.75mm |
| α | 15° |
| Static C0 | 20.59KN |
| Weight | 0.288Kg |
