SKU: NJ415-SKF
SKF NJ415 Single Row Cylindrical Roller Bearing 75x190x45mm
SKF NJ415 Single Row Cylindrical Roller Bearing 75x190x45mm
Out of stock
Description
Description
|
SKF NJ Series Single Row Cylindrical Roller Bearings: The outer ring of this type has two integral flanges around which the cage and rollers are assembled, the inner raceway has a single flange permitting the ease of assembly but limiting axial location to one direction. Benefits: Axial location, ease of assembly and fitting |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 75mm
- Outside Diameter:
- 190mm
- Width:
- 45mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 75mm |
|---|---|
| D | 190mm |
| B | 45mm |
| Dynamic load C | 264 kN |
| Static load Co | 280 kN |
| Fatigue load limit Pu | 34 kN |
| Reference speed | 4000 rpm |
| Limiting speed | 4800 rpm |
| Weight | 6.4 kg |
| d1 | 116mm |
| D1 | 148mm |
| F,E | 104.5mm |
| r1r2 min | 3mm |
| r3r4 min | 3mm |
| S | 3.8mm |
| da min | 91mm |
| da max | 101mm |
| db | 119mm |
| Da max | 174mm |
| ra max | 2.5mm |
| rb max | 2.5mm |
| kr | 0.15 |
| Angle ring | HJ415 |
| Angle Ring Weight | 0.71 kg |
| B1 | 13mm |
| B2 | 21.5mm |
