SKU: KR72PPB-MB-IKO
IKO KR72PPB Contact Sealed Crowned Cam Follower 72x29x24 M24x1.5 Thread
IKO KR72PPB Contact Sealed Crowned Cam Follower 72x29x24 M24x1.5 Thread
Out of stock
Description
Description
KR-PPB Series Crowned Cam Followers: Manufactured with needle rollers permitting a thick outer ring allowing for heavy loads and shock to be supported, axial guidance is provided by a flange on the stud side and a pressed on side washer. These cam followers are supplied with contact seals on both sides. |
- Brand / Quality:
- IKO - High Quality
- Outside Diameter:
- 72mm
- Width:
- 29mm
- Pitch:
- M24x1.5
Technical
Technical
| D | 72mm |
|---|---|
| C | 29mm |
| d(Stud Diameter) | 24mm |
| B | 80mm |
| B1 | 49.5mm |
| B2 | 11mm |
| C1 | 0.8mm |
| d1 | 44mm |
| G | M24x1.5 |
| G1 | 25mm |
| M1 | 4mm |
| r min | 1.1mm |
| SW | 14mm |
| Dynamic load | 26000 N |
| Static load | 48000 N |
| Fatigue load limit Pu | 6000 N |
| Radial dynamic load | 100000 N |
| Radial static load | 143000 N |
| Speed rating | 1900 rpm |
| Weight | 1010 g |
