SKF KMT32 Precision Lock Nut with Locking Pins M160x3mm

Name: SKF KMT32 Precision Lock Nut with Locking Pins M160x3mm
Brand: SKF
SKU: KMT32-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Precision KMT Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation and a chamfered front face for ease of access to the radial locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments.
Benefits: Efficient, secure, inexpensive, removable and re-useable

Brand / Quality:: SKF - High Quality
Thread Size:: M160x3

Technical

d1	182mm
d2	195mm
d3	184mm
d4	162mm
B	32mm
b	14mm
h	6mm
Axial load capacity	1100 kN
Loosening torque	1600 Nm
Weight	2.1 kg
G	M160x3
Spanner	TMFN30-40
Grub screw	M10
Screw torque	35 Nm
