SKU: DGE12E-DURB
Durbal DGE12E Maintenance Required Steel / Steel Spherical Plain Bearing 12x22x10mm
Durbal DGE12E Maintenance Required Steel / Steel Spherical Plain Bearing 12x22x10mm
Out of stock
Share this product
Description
Description
DURBAL Maintenance Required Spherical-Plain Bearing - Sliding Combination Steel/Steel: These spherical bearings consist of a hardened, phosphated steel joint ball and a hardened, phosphated, single split steel outer ring with split, oil groove and drill holes. (Outer ring has a split from size 15) For use with high and alternating loads. Temperature range: -40 deg C to +200 deg C.
Note: Single Split outer ring from size 15
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 12mm
Technical
Technical
| d | 12mm |
|---|---|
| d1 | 15mm |
| D | 22mm |
| dk | 18mm |
| B | 10mm |
| C | 7mm |
| rs | 0.3mm |
| r1s | 0.3mm |
| tilt angle α | 11 deg |
| weight | 0.016kg |
| basic load rating dyn C | 10.8 kN |
| basic load rating stat Co | 54 kN |
| CN | 32-68 µm |
