SKU: DGE10E-DURB
Durbal DGE10E Maintenance Required Steel / Steel Spherical Plain Bearing 10x19x9mm
Durbal DGE10E Maintenance Required Steel / Steel Spherical Plain Bearing 10x19x9mm
Out of stock
Share this product
Description
Description
DURBAL Maintenance Required Spherical-Plain Bearing - Sliding Combination Steel/Steel: These spherical bearings consist of a hardened, phosphated steel joint ball and a hardened, phosphated, single split steel outer ring with split, oil groove and drill holes. (Outer ring has a split from size 15) For use with high and alternating loads. Temperature range: -40 deg C to +200 deg C.
Note: Single Split outer ring from size 15
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 10mm
Technical
Technical
| d | 10mm |
|---|---|
| d1 | 13mm |
| D | 19mm |
| dk | 16mm |
| B | 9mm |
| C | 6mm |
| rs | 0.3mm |
| r1s | 0.3mm |
| tilt angle α | 12 deg |
| weight | 0.011kg |
| basic load rating dyn C | 8.15 kN |
| basic load rating stat Co | 40 kN |
| CN | 32-68 µm |
