SKU: C2244K-SKF
SKF C2244K Carb Toroidal Roller Bearing Taper Bore 200x400x108mm
SKF C2244K Carb Toroidal Roller Bearing Taper Bore 200x400x108mm
Out of stock
Share this product
Description
Description
|
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance. Benefits: High radial and axial loads, misalignment, taper and parallel bore options |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 200mm
- Outside Diameter:
- 400mm
- Width:
- 108mm
- Seals / Shields:
- None
Technical
Technical
| d | 200mm |
|---|---|
| D | 400mm |
| B | 108mm |
| Dynamic load C | 2000 kN |
| Static load Co | 2500 kN |
| Fatigue load limit Pu | 216 kN |
| Reference speed | 1500 rpm |
| Limiting speed | 2000 rpm |
| d2 | 259mm |
| d3 | 280mm |
| D1 | 350mm |
| B1 | 161mm |
| B2 | 35mm |
| s1 | 4mm |
| s2 | 20.5mm |
| da max | 295mm |
| db min | 233mm |
| Da min | 320mm |
| Da max | 383mm |
| Ba min | 21mm |
| Ca min | 1.7mm |
| ra max | 3mm |
| Misalignment factor k1 | 0.113 |
| Operating clearance factor k2 | 0.101 |
| Weight | 69 kg |
