SKU: BB-51104-B180-GL-D
xiros xirodur BB51104B180GLD Double Row Axial Ball Bearing with Glass Balls 20x47x10mm - Allow 2-3 Days
xiros xirodur BB51104B180GLD Double Row Axial Ball Bearing with Glass Balls 20x47x10mm - Allow 2-3 Days
Out of stock
Description
Description
|
IGUS xiros® xirodur® B180 Double Row Axial Ball Bearings: The ball bearing material xirodur® B180 offers extreme media resistance. These double row axial ball bearings made of plastics are designed for absorbing thrust loads. Double row axial ball bearings support higher loads compared to the single row version of this bearing. These bearings contain glass balls and can be used in the temperature range of up to +80 deg C. Benefits: Lubrication and maintenance-free, higher loads compared to single row version, corrosion resistant, non-magnetic. |
- Brand / Quality:
- Igus - High Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 47mm
- Width:
- 10mm
Technical
Technical
| d1 | 20mm |
|---|---|
| d2 | 47mm |
| d3 | 46.5mm |
| h | 10mm |
| Static bearing load | 975 N |
| Dynamic bearing load | 1215 N |
| Max speed | 460 rpm |
| Housing | B180 |
| Ball material | Glass |
