SKU: 16009-2RSR-FAG
FAG 16009.2RSR Rubber Sealed Deep Groove Ball Bearing 25x47x8mm
FAG 16009.2RSR Rubber Sealed Deep Groove Ball Bearing 25x47x8mm
Equivalent to: 16009NSE 16009DU 160092RS16009RSH 16009P 16009RSR 16009LU 16009NSE 16009DDU 160092RS 160092RS1 160092RSH 16009PP 16009LLU
Out of stock
Share this product
Description
Description
|
Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing |
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 25mm
- Outside Diameter:
- 47mm
- Width:
- 8mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
Technical
| d | 25mm |
|---|---|
| D | 47mm |
| B | 8mm |
| Dynamic load C | 7.2 kN |
| Static load Co | 4.65 kN |
| Fatigue load limit Pu | 2.15 kN |
| Reference speed | 12000 rpm |
| Limiting speed | 22900 rpm |
| Mass | 0.062 kg |
| d1 | 32.2mm |
| D2 | 39.7mm |
| r1r2 min | 0.3mm |
| da min | 27 |
