SKU: 10B-1-SYNO-50FT-RENOLD
Renold SYNO 10B-1 BS Simplex Roller Chain 5/8mm Pitch - 50 Feet Length Allow 2-3 Days
Renold SYNO 10B-1 BS Simplex Roller Chain 5/8mm Pitch - 50 Feet Length Allow 2-3 Days
Equivalent to: SNX10B-1
Out of stock
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Simplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 15.88mm = 0.625 (5/8) inch
Technical
Technical
| Pitch (A) | 0.625 inch |
|---|---|
| Pitch (A) | 15.875mm |
| Inside Width min (B) | 9.65mm |
| Roller Diameter max (C) | 10.16mm |
| Plate Height max (D) | 14.6mm |
| Plate Width Inner max (E) | 1.55mm |
| Plate Width Outer max (F) | 1.55mm |
| Pin Diameter max (G) | 5.08mm |
| Pin Length max (H1) | 18.8mm |
| Connecting link extension max (J) | 2.5mm |
| ISO606 Tensile strength min | 22200 N |
| Weight | 0.96 kg/m |
