SKU: UCT.205-16.TS.CHAL

Challenge / FK UCT205-16 Imperial Cast Iron Take Up Unit Housing with 1 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge / FK UCT205-16 Imperial Cast Iron Take Up Unit Housing with 1 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price €36,29 ex VAT
Regular price Sale price €36,29 ex VAT
Sale Sold out

Equivalent to: UCT.205-16

In stock

Price Break
3+ €27,58
5+ €26,03
9+ €25,72
19+ €25,41
49+ €25,10
74+ €24,79
99+ €23,24
199+ €22,93
249+ €22,62
499+ €22,31
999+ €21,69
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Shaft Diameter d 1 inch
Nut Slot Width o 16mm
Distance g 10mm
Dimention p 51mm
Dimention q 32mm
Hole s 19mm
Dimention b 51mm
Slot Width k 12mm
Distance Between Slots e 76mm
Overall Casting Depth a 89mm
Width w 97mm
Diameter j 32mm
Casting Width at Slots l 24mm
Dimension h 62mm
Grub Screws x 2 1/4 - 28UNF
Load Rating (Dynamic) 1100kg
Load Rating (Static) 710kg
Max Speed 3400 rev/min
Grease Nipple Thread Size M6
Working Temperature -30°C to +120°C
Insert No UC205-16
Housing No T205
