SKU: UCPX.10
UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
- Regular price
- €82,82 ex VAT
- Sale price
- €82,82
- Regular price
-
In stock
Quantity Price Breaks
3
€73,71
4
€69,57
9
€68,74
19
€67,91
49
€67,08
99
€66,26
499
€62,12
999
€61,29
1999
€60,46
2999
€59,63
4999
€57,97
SKU:
UCPX.10
UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
- Regular price
- €82,82 ex VAT
- Sale price
- €82,82
- Regular price
-
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 50mm |
| h | = | 63.5mm |
| a | = | 241mm |
| e | = | 171mm |
| b | = | 73mm |
| s2 | = | 36mm |
| s1 | = | 20mm |
| g | = | 27mm |
| w | = | 126mm |
| B1 | = | 55.6mm |
| n | = | 22.2mm |
| Bolt Size | = | M16 |
| Weight | = | 4.4 kg |
| Dynamic load | = | 3400 kgf |
| Static load | = | 2550 kgf |
| Rec max speed | = | 3100 rpm |
