SKU: UCFC.215
UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
- Regular price
- €197,66 ex VAT
- Sale price
- €197,66
- Regular price
-
Not in stock
Quantity Price Breaks
3
€175,92
4
€166,03
9
€164,06
19
€162,08
49
€160,10
99
€158,13
499
€148,25
999
€146,27
1999
€144,29
2999
€142,32
4999
€138,36
SKU:
UCFC.215
UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
- Regular price
- €197,66 ex VAT
- Sale price
- €197,66
- Regular price
-
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| d | = | 75mm |
| a | = | 220mm |
| P | = | 184mm |
| e | = | 130.1mm |
| i | = | 18mm |
| L | = | 56mm |
| s | = | 19mm |
| j | = | 16mm |
| k | = | 18mm |
| g | = | 40mm |
| f | = | 160mm |
| z | = | 62.5mm |
| Bi | = | 77.8mm |
| n | = | 33.3mm |
| Bolt Size | = | M16 |
| Weight | = | 7.3 kg |
| Dynamic load | = | 5190 kgf |
| Static load | = | 4190 kgf |
