SKU: NAO40X55X17.OH-EU
NAO40x55x17 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve and Oil Groove
- Regular price
- €24,01 ex VAT
- Sale price
- €24,01
- Regular price
-
In stock
Quantity Price Breaks
10
€21,37
19
€20,17
29
€19,93
39
€19,69
49
€19,45
74
€19,21
99
€18,01
199
€17,77
249
€17,53
499
€17,29
999
€16,81
SKU:
NAO40X55X17.OH-EU
NAO40x55x17 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve and Oil Groove
- Regular price
- €24,01 ex VAT
- Sale price
- €24,01
- Regular price
-
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
Technical
| d | = | 40mm |
| D | = | 55mm |
| B | = | 17mm |
| Dynamic load C | = | 21600 N |
| Static load Co | = | 46500 N |
| Fatigue load limit Pu | = | 5600 N |
| Speed in grease | = | 6300 rpm |
| Speed in oil | = | 9000 rpm |
| E | = | 50mm |
| F | = | 45mm |
| r1r2 min | = | 0.3mm |
| S (axial disp) | = | 0.8mm |
| da | = | 49.2mm |
| db | = | 44.5mm |
| Da | = | 50.5mm |
| Db | = | 45.6mm |
| ra max | = | 0.3mm |
| Weight | = | 130 g |
