RHP MSF4 Imperial Four Bolt Square Cast Iron Flange Housing and 4 inch Bore Grub Screw Insert
RHP MSF4 Imperial Four Bolt Square Cast Iron Flange Housing and 4 inch Bore Grub Screw Insert
Regular price
€893,18
ex VAT
Regular price
Sale price
€893,18
ex VAT
In stock
Price Break
10+
€678,78
20+
€640,64
30+
€633,02
40+
€625,39
50+
€617,76
75+
€610,14
100+
€572,00
200+
€564,38
250+
€556,75
500+
€549,12
1000+
€533,87
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 101.6mm = 4 inch
- Style:
- MSF
- Bolt Hole Centres:
- 211.125mm = 8.312 inch
Technical
Technical
| Bore | 4 inch |
|---|---|
| L | 10.531 inch |
| H | 9.272 inch |
| J | 8.312 inch |
| G | 1 inch |
| A | 3.287 inch |
| A1 | 4.998 inch |
| A4 | 1.26 inch |
| B | 4.625 inch |
| s | 1.94 inch |
| d1 | 5.135 inch |
| Dynamic load cr | 157000 N |
| Static load Cor | 122020 N |
| Rec max speed | 1600 rpm |
| Weight | 24.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=3095-4G+insonly">3095-4G Click Here</a> |
| Casting group | 13 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
