RHP MSF3-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 3-1/2 inch Bore Grub Screw Insert
RHP MSF3-1/2 Imperial Four Bolt Square Cast Iron Flange Housing and 3-1/2 inch Bore Grub Screw Insert
Regular price
€595,55
ex VAT
Regular price
Sale price
€595,55
ex VAT
In stock
Price Break
10+
€452,59
20+
€427,17
30+
€422,08
40+
€417,00
50+
€411,91
75+
€406,82
100+
€381,40
200+
€376,31
250+
€371,23
500+
€366,14
1000+
€355,97
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 88.9mm = 3.5 (3-1/2) inch
- Style:
- MSF
- Bolt Hole Centres:
- 171.45mm = 6.75 inch
Technical
Technical
| Bore | 3-1/2 inch |
|---|---|
| L | 8.406 inch |
| H | 7.736 inch |
| J | 6.75 inch |
| G | 0.75 inch |
| A | 2.429 inch |
| A1 | 3.967 inch |
| A4 | 1.024 inch |
| B | 3.781 inch |
| s | 1.564 inch |
| d1 | 4.396 inch |
| Dynamic load cr | 96000 N |
| Static load Cor | 71500 N |
| Rec max speed | 1900 rpm |
| Weight | 13.2 kg |
| Insert | <a href="advanced_search_result.php?keywords=1090-3-1/2G+insonly">1090-3-1/2G Click Here</a> |
| Casting group | 12 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
