• Timken 30207 Metric Taper Roller Bearing 35x72x18.25mm
  • Timken
1 2

SKU: 30207-TIM

Timken 30207 Metric Taper Roller Bearing 35x72x18.25mm

Timken 30207 Metric Taper Roller Bearing 35x72x18.25mm
€36,01 ex VAT
€36,01 ex VAT
Sale Sold out

In stock

Price Break
10+ €27,36
20+ €25,83
30+ €25,52
40+ €25,21
50+ €24,90
75+ €24,60
100+ €23,06
200+ €22,75
250+ €22,45
500+ €22,14
1000+ €21,52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
35mm
Outside Diameter:
72mm
Width:
18.25mm
Technical
d 35mm
D 72mm
T 18.25mm
Dynamic load 51.2 kN
Static load 56 kN
Fatigue load limit Pu 6.1 kN
Reference speed 7000 rpm
Limiting speed 9500 rpm
Mass 0.32 kg
d1 51.8mm
B 17mm
C 15mm
r1r2 min 1.5mm
r3r4 min 1.5mm
a 15mm
da max 44mm
db min 42mm
Da min 62mm
Da max 65mm
Db min 67mm
Ca min 3mm
Cb min 3mm
ra max 1.5mm
rb max 1.5mm
e 0.37
Y 1.6
Y0 0.9
